CHIMEI was the fourth largest TFT-LCD panel manufacturer in the world. CHIMEI has a market foundation in the field of industrial display.The series of CHIMEI industrial display are still on sale and are manufactured by Chimei Innolux.
| Brand | Model | Size | Resolution | Brightness | Viewing angle | Interface | Contrast | Operating Temp. | Mass Production |
|---|---|---|---|---|---|---|---|---|---|
| CHIMEI | LQ035NC111 | 3.5" | 320(RGB)×240 | 300 cd/m² | 60/60/50/55 | TTL (1 ch, 8-bit) | 400:1 | -20 ~ 70 °C | In Production |
| CHIMEI | G057AGE-T01 | 5.7" | 320(RGB)×240 | 500 cd/m² | 80/80/70/70 | TTL (1 ch, 6-bit) | 800:1 | -30 ~ 85 °C | Discontinued |
| CHIMEI | G057VGE-T01 | 5.7" | 640(RGB)×480 | 450 cd/m² | 80/80/70/70 | TTL (1 ch, 6-bit) | 800:1 | -30 ~ 85 °C | In Production |
| CHIMEI | G070Y2-L01 | 7.0" | 800(RGB)×480 | 500 cd/m² | 70/70/60/60 | LVDS (1 ch, 6/8-bit) | 600:1 | -30 ~ 85 °C | In Production |
| CHIMEI | G070Y2-T02 | 7.0" | 800(RGB)×480 | 500 cd/m² | 70/70/60/60 | TTL (1 ch, 6/8-bit) | 600:1 | -30 ~ 85 °C | In Production |
| CHIMEI | G070Y3-T01 | 7.0" | 800(RGB)×480 | 600 cd/m² | 70/70/60/60 | TTL (1 ch, 6-bit) | 650:1 | -30 ~ 85 °C | In Production |
| CHIMEI | LSA40AT9001 | 10.4" | 800(RGB)×600 | 250 cd/m² | 70/70/50/60 | Parallel RGB (1 ch, 6/8-bit) | 500:1 | -10 ~ 50 °C | Discontinued |
| CHIMEI | G104V1-T03 | 10.4" | 640(RGB)×480 | 500 cd/m² | 88/88/88/88 | CMOS/TTL (1 ch, 6-bit) | 1500:1 | -30 ~ 80 °C | Discontinued |
| CHIMEI | G104AGE-L02 | 10.4" | 800(RGB)×600 | 400 cd/m² | 80/80/70/70 | LVDS (1 ch, 6/8-bit) | 700:1 | -30 ~ 85 °C | In Production |
| CHIMEI | G104S1-L01 | 10.4" | 800(RGB)×600 | 400 cd/m² | 80/80/70/70 | LVDS (1 ch, 6/8-bit) | 700:1 | -20 ~ 70 °C | In Production |
| CHIMEI | G104X1-L03 | 10.4" | 1024(RGB)×768 | 350 cd/m² | 88/88/88/88 | LVDS (1 ch, 6/8-bit) | 1000:1 | -20 ~ 70 °C | In Production |
| CHIMEI | G104X1-L04 | 10.4" | 1024(RGB)×768 | 500 cd/m² | 88/88/88/88 | LVDS (1 ch, 6/8-bit) | 1000:1 | -30 ~ 80 °C | In Production |
| CHIMEI | G121S1-L02 | 12.1" | 800(RGB)×600 | 600 cd/m² | 89/89/89/89 | LVDS (1 ch, 6/8-bit) | 1500:1 | -30 ~ 80 °C | In Production |
| CHIMEI | G121X1-L04 | 12.1" | 1024(RGB)×768 | 500 cd/m² | 80/80/70/70 | LVDS (1 ch, 6/8-bit) | 700:1 | -30 ~ 70 °C | Discontinued |
