Auo display screen is mainly used for industrial display, medical screen, automotive display etc. Auo screen are mainly 10.1-23 inches, Auo lcd reliability is very good and many models with widely opearting temperature and high brightness.
| Brand | Model | Size | Resolution | Brightness | Viewing angle | Interface | Contrast | Operating Temp. | Mass Production |
|---|---|---|---|---|---|---|---|---|---|
| AUO | G043FTN01.0 | 4.3" | 480(RGB)×272 | 550 cd/m² | 80/80/55/65 | Parallel RGB 24bit | 400:1 | -20 ~ 70 °C | In Production |
| AUO | G050VTN01.0 | 5.0" | 800(RGB)×480 | 370 cd/m² | 75/75/65/75 | TTL (1 ch, 8-bit) | 600:1 | -20 ~ 70 °C | In Production |
| AUO | G050VTN01.1 | 5.0" | 800(RGB)×480 | 1000 cd/m² | 75/75/65/75 | TTL (1 ch, 8-bit) | 600:1 | -20 ~ 70 °C | In Production |
| AUO | G057QN01 V2 | 5.7" | 320(RGB)×240 | 800 cd/m² | 80/80/70/70 | CMOS (1 ch, 6-bit) | 800:1 | -30 ~ 85 °C | In Production |
| AUO | G057VTN01.0 | 5.7" | 640(RGB)×480 | 530 cd/m² | 80/80/70/70 | CMOS (1 ch, 6-bit) | 800:1 | -30 ~ 85 °C | Discontinued |
| AUO | G065VN01 V2 | 6.5" | 640(RGB)×480 | 800 cd/m² | 80/80/70/70 | LVDS (1 ch, 6/8-bit) | 600:1 | -30 ~ 80 °C | In Production |
| AUO | G070VW01 V0 | 7.0" | 800(RGB)×480 | 400 cd/m² | 80/80/80/80 | LVDS (1 ch, 6/8-bit) | 750:1 | -30 ~ 85 °C | In Production |
| AUO | C080EAN04.1 | 8.0" | 1280(RGB)×720 | 750 cd/m² | 80/80/80/80 | LVDS (1 ch, 8-bit) | 1000:1 | -30 ~ 85 °C | In Production |
| AUO | G084SN03 V3 | 8.4" | 800(RGB)×600 | 250 cd/m² | 80/80/80/60 | LVDS (1 ch, 6/8-bit) | 600:1 | -20 ~ 70 °C | In Production |
| AUO | G084SN05 V9 | 8.4" | 800(RGB)×600 | 450 cd/m² | 80/80/80/60 | LVDS (1 ch, 6/8-bit) | 600:1 | -30 ~ 85 °C | In Production |
| AUO | G090VTN02.0 | 9.0" | 800(RGB)×480 | 300 cd/m² | 70/70/50/70 | LVDS (1 ch, 8-bit) | 500:1 | -20 ~ 75 °C | Discontinued |
| AUO | A101VW01 V3 | 10.1" | 800(RGB)×480 | 300 cd/m² | 65/65/45/65 | Parallel RGB 18bit | 500:1 | -10 ~ 60 °C | In Production |
| AUO | G101STN01.0 | 10.1" | 1024(RGB)×600 | 250 cd/m² | 70/70/60/60 | LVDS (1 ch, 6/8-bit) | 500:1 | -10 ~ 60 °C | In Production |
| AUO | G101STN01.2 | 10.1" | 1024(RGB)×600 | 350 cd/m² | 70/70/60/60 | LVDS (1 ch, 6/8-bit) | 500:1 | -10 ~ 60 °C | In Production |
| AUO | C101EAN01.0 | 10.1" | 1280(RGB)×720 | 400 cd/m² | 80/80/80/80 | LVDS (1 ch, 8-bit) | 1000:1 | -30 ~ 85 °C | Discontinued |
| AUO | G101EAN02.1 | 10.1" | 1280(RGB)×800 | 400 cd/m² | 89/89/89/89 | LVDS (1 ch, 8-bit) | 800:1 | -20 ~ 60 °C | In Production |
| AUO | G101EVN03.1 | 10.1" | 1280(RGB)×800 | 1000 cd/m² | 85/85/85/85 | LVDS (1 ch, 6/8-bit) | 1300:1 | -20 ~ 60 °C | In Production |
| AUO | G101UAN01.0 | 10.1" | 1920(RGB)×1200 | 380 cd/m² | 89/89/89/89 | eDP (2 Lanes) | 800:1 | -10 ~ 60 °C | In Production |
| AUO | C103VAN01.1 | 10.3" | 1280(RGB)×480 | 600 cd/m² | 80/80/80/80 | LVDS (1 ch, 8-bit) | 800:1 | -30 ~ 85 °C | In Production |
| AUO | G104VN01 V1 | 10.4" | 640(RGB)×480 | 450 cd/m² | 80/80/60/80 | LVDS (1 ch, 6/8-bit) | 700:1 | -30 ~ 85 °C | In Production |
| AUO | A104SN03 V1 | 10.4" | 800(RGB)×600 | 350 cd/m² | 75/75/50/60 | TTL(1ch,6/8-bit)+SPI | 500:1 | -10 ~ 60 °C | In Production |
| AUO | G121SN01 V4 | 12.1" | 800(RGB)×600 | 450 cd/m² | 80/80/65/75 | LVDS (1 ch, 6/8-bit) | 700:1 | -30 ~ 85 °C | In Production |
| AUO | G121XN01 V0 | 12.1" | 1024(RGB)×768 | 500 cd/m² | 80/80/80/80 | LVDS (1 ch, 6/8-bit) | 700:1 | -30 ~ 85 °C | In Production |
| AUO | G121EAN01.0 | 12.1" | 1280(RGB)×800 | 500 cd/m² | 89/89/89/89 | LVDS (1 ch, 6/8-bit) | 1000:1 | -30 ~ 85 °C | In Production |
| AUO | G133HAN01.0 | 13.3" | 1920(RGB)×1080 | 450 cd/m² | 89/89/89/89 | LVDS (2 ch, 8-bit) | 800:1 | -20 ~ 70 °C | In Production |
| AUO | G150XTN03.5 | 15.0" | 1024(RGB)×768 | 350 cd/m² | 80/80/70/80 | LVDS (1 ch, 6/8-bit) | 800:1 | 0 ~ 65 °C | In Production |
| AUO | G150XTN06.1 | 15.0" | 1024(RGB)×768 | 500 cd/m² | 80/80/70/80 | LVDS (1 ch, 6/8-bit) | 800:1 | -20 ~ 70 °C | Discontinued |
| AUO | G150XTN06.8 | 15.0" | 1024(RGB)×768 | 450 cd/m² | 80/80/70/80 | LVDS (1 ch, 6/8-bit) | 800:1 | -30 ~ 85 °C | In Production |
| AUO | G156XTN01.0 | 15.6" | 1366(RGB)×768 | 400 cd/m² | 85/85/50/80 | LVDS (1 ch, 8-bit) | 800:1 | -30 ~ 85 °C | In Production |
| AUO | G156HAN02.0 | 15.6" | 1920(RGB)×1080 | 500 cd/m² | 89/89/89/89 | eDP (2 Lanes) | 1000:1 | -20 ~ 70 °C | In Production |
| AUO | G170EG01 V1 | 17.0" | 1280(RGB)×1024 | 350 cd/m² | 80/80/60/80 | LVDS (2 ch, 8-bit) | 800:1 | -30 ~ 85 °C | In Production |
| AUO | G173HW01 V0 | 17.3" | 1920(RGB)×1080 | 400 cd/m² | 80/80/60/80 | LVDS (2 ch, 8-bit) | 600:1 | 0 ~ 70 °C | In Production |
| AUO | G185XW01 V1 | 18.5" | 1366(RGB)×768 | 300 cd/m² | 85/85/80/80 | LVDS (1 ch, 8-bit) | 1000:1 | 0 ~ 60 °C | In Production |
| AUO | G190EAN01.0 | 19.0" | 1280(RGB)×1024 | 300 cd/m² | 89/89/89/89 | LVDS (2 ch, 8-bit) | 1000:1 | 0 ~ 50 °C | In Production |
| AUO | G190ETN01.2 | 19.0" | 1280(RGB)×1024 | 350 cd/m² | 85/85/80/80 | LVDS (2 ch, 8-bit) | 1000:1 | -30 ~ 85 °C | In Production |
| AUO | G215HAN01.0 | 21.5" | 1920(RGB)×1080 | 400 cd/m² | 89/89/89/89 | LVDS (2 ch, 8-bit) | 1000:1 | 0 ~ 60 °C | In Production |
| AUO | G215HVN01.0 | 21.5" | 1920(RGB)×1080 | 300 cd/m² | 89/89/89/89 | LVDS (2 ch, 8-bit) | 5000:1 | 0 ~ 50 °C | Discontinued |
| AUO | G220SVN01.0 | 22" | 1680(RGB)×1050 | 250 cd/m² | 89/89/89/89 | LVDS (2 ch, 8-bit) | 2000:1 | 0 ~ 50 °C | Discontinued |
| AUO | G230HAN01.1 | 23" | 1920(RGB)×1080 | 300 cd/m² | 89/89/89/89 | LVDS (2 ch, 8-bit) | 1000:1 | 0 ~ 50 °C | In Production |
