Innolux display as a leader in the field of industrial display screen. Innolux LCD has a strong reputation in contrast, brightness and viewing angle,Innolux corp merged with CHIMEI and TPO in 2010.At present, Innolux has a complete TFT LCD product line.
| Brand | Model | Size | Resolution | Brightness | Viewing angle | Interface | Contrast | Operating Temp. | Mass Production |
|---|---|---|---|---|---|---|---|---|---|
| Innolux | AT043TN24 V.7 | 4.3" | 480(RGB)×272 | 500 cd/m² | 70/70/50/70 | Parallel RGB (1 ch, 8-bit) | 500:1 | -20 ~ 70 °C | In Production |
| Innolux | AT043TN25 V.2 | 4.3" | 480(RGB)×272 | 500 cd/m² | 70/70/50/70 | Parallel RGB (1 ch, 8-bit) | 500:1 | -20 ~ 70 °C | In Production |
| Innolux | ZJ050NA-08C | 5.0" | 640(RGB)×480 | 250 cd/m² | 70/70/50/70 | Parallel RGB (1 ch, 8-bit) | 500:1 | -20 ~ 70 °C | In Production |
| Innolux | EJ050NA-01G | 5.0" | 800(RGB)×480 | 350 cd/m² | 70/70/50/70 | Parallel RGB (1 ch, 8-bit) | 500:1 | -20 ~ 70 ℃ | In Production |
| Innolux | AT056TN52 V.3 | 5.6" | 640(RGB)×480 | 200cd/m² | 70/70/50/70 | Parallel RGB (1 ch, 8-bit) | 500:1 | -20 ~ 70 °C | In Production |
| Innolux | AT056TN53 V.1 | 5.6" | 640(RGB)×480 | 350 cd/m² | 70/70/50/70 | Parallel RGB (1 ch, 6-bit) | 500:1 | -20 ~ 70 °C | In Production |
| Innolux | AT065TN14 | 6.5" | 800(RGB)×480 | 400 cd/m² | 70/70/50/70 | Parallel RGB (1 ch, 6/8-bit) | 500:1 | -30 ~ 85 °C | In Production |
| Innolux | AT070TN83 V.1 | 7.0" | 800(RGB)×480 | 300 cd/m² | 70/70/50/70 | TTL (1 ch, 6-bit) | 500:1 | -20 ~ 70 °C | In Production |
| Innolux | AT070TN84 V.1 | 7.0" | 800(RGB)×480 | 450 cd/m² | 70/70/50/70 | Parallel RGB (1 ch, 6-bit) | 500:1 | -30 ~ 85 °C | Discontinued |
| Innolux | AT070TN92 | 7.0" | 800(RGB)×480 | 250 cd/m² | 70/70/50/70 | Parallel RGB (1 ch, 6/8-bit) | 500:1 | -20 ~ 70 °C | In Production |
| Innolux | AT070TN94 | 7.0" | 800(RGB)×480 | 400 cd/m² | 70/70/50/70 | Parallel RGB (1 ch, 6/8-bit) | 500:1 | -30 ~ 85 °C | In Production |
| Innolux | NJ070NA-23A | 7.0" | 1024(RGB)×600 | 500 cd/m² | 75/75/70/75 | LVDS (1 ch, 6/8-bit) | 800:1 | -20 ~ 70 °C | In Production |
| Innolux | P070BAG-CM1 | 7.0" | 1024(RGB)×600 | 500 cd/m² | 75/75/70/75 | LVDS (1 ch, 6/8-bit) | 800:1 | -20 ~ 70 °C | Discontinued |
| Innolux | AT080TN64 | 8.0" | 800(RGB)×480 | 450 cd/m² | 70/70/50/70 | Parallel RGB (1 ch, 6/8-bit) | 500:1 | -30 ~ 85 °C | In Production |
| Innolux | EJ080NA-05B | 8.0" | 800(RGB)×600 | 250 cd/m² | 70/70/50/70 | Parallel RGB (1 ch, 6/8-bit) | 500:1 | -20 ~ 70 °C | In Production |
| Innolux | EJ080NA-04C | 8.0" | 1024(RGB)×768 | 250 cd/m² | 75/75/75/75 | LVDS (1 ch, 6/8-bit) | 700:1 | -10 ~ 50 °C | Discontinued |
| Innolux | AT090TN12 V.3 | 9.0" | 800(RGB)×480 | 250 cd/m² | 70/70/50/70 | TTL (1 ch, 6/8-bit) | 500:1 | -20 ~ 70 °C | In Production |
| InnoLux | EJ101IA-01G | 10.1" | 1280(RGB)×800 | 350 cd/m² | 85/85/85/85 | LVDS (1 ch, 8-bit) | 800:1 | -10 ~ 60 °C | In Production |
| InnoLux | G101ICE-L01 | 10.1" | 1280(RGB)×800 | 500 cd/m² | 85/85/85/85 | LVDS (1 ch, 6/8-bit) | 800:1 | -20 ~ 70 °C | In Production |
| InnoLux | AT102TN03 V.8 | 10.2" | 800(RGB)×480 | 350 cd/m² | 65/65/45/65 | TTL (1 ch, 6-bit) | 300:1 | -30 ~ 85 °C | In Production |
| InnoLux | G121XCE-L01 | 12.1" | 1024(RGB)×768 | 600 cd/m² | 89/89/89/89 | LVDS (1 ch, 6/8-bit) | 1000:1 | -30 ~ 85 °C | In Production |
| InnoLux | G121XCE-L02 | 12.1" | 1024(RGB)×768 | 500 cd/m² | 89/89/89/89 | LVDS (1 ch, 6/8-bit) | 1000:1 | -30 ~ 70 °C | In Production |
| InnoLux | G150XGE-L04 | 15.0" | 1024(RGB)×768 | 400 cd/m² | 80/80/70/70 | LVDS (1 ch, 6/8-bit) | 700:1 | -30 ~ 80 °C | Discontinued |
| InnoLux | G150XNE-L01 | 15.0" | 1024(RGB)×768 | 500 cd/m² | 88/88/88/88 | LVDS (1 ch, 6/8-bit) | 2500:1 | -30 ~ 80 °C | In Production |
| InnoLux | G150XNE-L03 | 15.0" | 1024(RGB)×768 | 300 cd/m² | 88/88/88/88 | LVDS (1 ch, 6/8-bit) | 2000:1 | -20 ~ 70 °C | In Production |
| InnoLux | G156HCE-L01 | 15.6" | 1920(RGB)×1080 | 450 cd/m² | 85/85/85/85 | LVDS (2 ch, 8-bit) | 800:1 | -30 ~ 85 °C | In Production |
